S1 | Unmanned Ground Vehicles

S1 All-Terrain Wheeled Quadruped Robot

Protection rating: IP67 (temporary full submersion)
Weight (with battery): 35 kg
Standing dimensions (L × W × H): 0.82 × 0.43 × 0.57 m

Price on RequestUSD · EXW Hong Kong

Send inquiry

SKUS1

MOQ1 SET

Lead timeTo be confirmed in the quotation for the selected configuration and destination

Price basisUSD · EXW Hong Kong

Product Overview

The S1 All-Terrain Wheeled Quadruped Robot is an unmanned ground vehicle from Aerosys Technology. Wheeled-legged quadruped built for all-terrain inspection and patrol. Published data lists maximum continuous step height as 30 cm and maximum operating speed as 2 m/s. The selected configuration is quoted as a set, with included items and documentation itemised. The datasheet also states battery: hot-swappable dual battery system.

Technical Specifications

Parameter	Value
Chassis
Standing dimensions (L × W × H)	0.82 × 0.43 × 0.57 m
Weight (with battery)	35 kg
Protection rating	IP67 (temporary full submersion)
Mobility
Maximum tested speed	9 m/s (laboratory benchmark)
Maximum operating speed	2 m/s
Payload and power
Effective payload (standard terrain)	35 kg
Effective payload (all-terrain)	25 kg
Operating time / range (no payload)	3.5-5 h / 16-20 km
Operating time / range (with payload)	2.5-3.5 h / 12-15 km
Battery	hot-swappable dual battery system
Power input	24V / 72V
Additional published specifications
Operating temperature	-30 °C to 55 °C
Maximum continuous step height	30 cm
Maximum slope angle	45°
LiDAR sensors	2
Wide-angle cameras	2
Computing	3 × octa-core 64-bit industrial processors (16 GB + 128 GB)
Navigation	SLAM mapping & navigation, omnidirectional obstacle avoidance
System noise	≤55 dB
Hardware interfaces	Gigabit Ethernet, USB, GMSL

Configuration and supply

MOQ1 SET

PricePrice on Request

Price basisEXW Hong Kong; freight, insurance, import duty, VAT and destination charges excluded.

Supply scopeItemised in the quotation for the selected configuration.

Lead timeConfirmed in the quotation for the selected configuration and destination.

PackingDimensions and gross weight confirmed with the quotation.

Application Scenarios

Perimeter patrol of industrial sites, depots and construction yards
Pipeline, powerline and substation corridor inspection
Equipment and material transport over rough ground
Emergency and disaster response support
Mining, quarry and agricultural site work

Related applications

Industrial Plant & Pipeline Inspection with UGV and UAV

Recommended: ZT30

View application →

UAV and UGV Inspection for Open-Pit Mines and Quarries

Recommended: AT-G22, ZT30, G30

View application →

Chemical Plant, Hazmat and Fire Reconnaissance

Recommended: AT-G22, AT-135T, G30

View application →

Procurement and export control

Company KYC: legal entity name, registration, registered address and beneficial ownership.
End-user certificate (EUC): identification of the end user, end use and destination.
Import authorisation: an import licence or permit where the destination requires one.
Sanctions screening: checks against applicable export-control and sanctions lists.
Letter of intent: programme, quantity and configuration on company letterhead for formal procurement.

Aerosys supplies the platform and its documented configuration. Weapon integration and tactical employment are outside the scope of this page. Every order is subject to export-control and end-user review.

Documents are reviewed before a quotation is accepted. Requirements vary by destination and configuration.

Frequently Asked Questions

What is the Effective payload (standard terrain) of the S1 All-Terrain Wheeled Quadruped Robot?

The published Effective payload (standard terrain) is 35 kg.

What endurance and range are published for the S1 All-Terrain Wheeled Quadruped Robot?

Operating time / range (no payload): 3.5-5 h / 16-20 km. Actual figures depend on payload, speed, altitude and mission profile; confirm the intended configuration before order.

What is included in one set?

The quotation itemises the selected items and accessories, ground equipment where applicable, and documentation for the chosen configuration. MOQ is 1 SET; lead time is confirmed per order.

Can the S1 All-Terrain Wheeled Quadruped Robot be configured for a specific mission?

Send the payload or sensor, interface, operating environment, quantity and destination. The configuration and supply scope is confirmed before quotation.

What documents are required before export?

Company KYC, an end-user certificate and end-use statement, and an import licence or authorisation where the destination requires one. Orders are subject to sanctions and export-control screening.

How are price and shipping handled?

Prices are in USD on an EXW Hong Kong basis. Freight, insurance, import duty, VAT and destination charges are additional. Packing and shipping are confirmed with the quotation.
