Skydroid G11
- Display: 4.5-inch touchscreen
- Screen resolution: 1920 × 1080
- Operating system: Linux
Product overview
11-channel dual-band ground station built around a 4.5-inch 1920 × 1080 touchscreen and a Linux system, weighing 480 g. Automatic frequency hopping across 2.4 GHz and 5.8 GHz gives up to 9 km of control range, and the 10,000 mAh battery is rated at 5-6 hours. Ships with the GR01 receiver.
Choosing your configuration
Before choosing a controller, identify the air unit, vehicle interface, video input and ground-station software. Tell us which equipment you already have; the exact controller and air-unit combination determines compatibility.
Aerosys Technology is an authorized Skydroid dealer. Please confirm the exact model, included items and support terms in your quotation.
Pricing and quotation
Where a price is displayed, it applies to the listed configuration and quantity tier. Ask for a quotation to confirm included items, optional accessories, shipping charges and the current order total. Availability, delivery and support terms will be confirmed for your order.
Product questions
What should I check before selecting this model?
Before choosing a controller, identify the air unit, vehicle interface, video input and ground-station software. Tell us which equipment you already have; the exact controller and air-unit combination determines compatibility.
What information do you need for a quotation?
Send the model or SKU, quantity, destination and intended civil or commercial use through the inquiry form or the existing email and WhatsApp channels. Include the equipment you plan to connect so we can discuss the configuration.
Does the displayed price cover every configuration?
Where a price is displayed, it applies to the listed configuration and quantity tier. Ask for a quotation to confirm included items, optional accessories, shipping charges and the current order total. Availability, delivery and support terms will be confirmed for your order.
- Display:4.5-inch touchscreen
- Screen resolution:1920 × 1080
- Operating system:Linux
- Memory:128 MB RAM + 128 MB storage
- Channels:11
- Frequency:2.4 GHz / 5.8 GHz, automatic frequency hopping
In the box. G11 controller; GR01 receiver (G12RX or GR00, selected at order time); GR01 power cable; 2 GR01 feeder cables (50 cm fitted, up to 1.5 m); 2 dual-band 2.4/5.8 GHz antennas with RP-SMA connectors; 1 SBUS data cable matched to your flight controller; R20 LAN cable; GR01-PWM twisted-pair lead; USB-C data cable; EPP carry case.
Configuration and application fit
Published selection points
- Published specification: Display: 4.5-inch touchscreen
- Published specification: Screen resolution: 1920 × 1080
- Published specification: Operating system: Linux
- Published specification: Memory: 128 MB RAM + 128 MB storage
- Published specification: Channels: 11
- Published specification: Frequency: 2.4 GHz / 5.8 GHz, automatic frequency hopping
For a configuration quote, send the model, quantity, destination and intended civil or commercial use. Add the required interface, payload, cargo or sensor details where relevant so the supply scope can be checked clearly.
Technical Specifications
| Parameter | Value |
|---|---|
| Display | 4.5-inch touchscreen |
| Screen resolution | 1920 × 1080 |
| Operating system | Linux |
| Memory | 128 MB RAM + 128 MB storage |
| Channels | 11 |
| Frequency | 2.4 GHz / 5.8 GHz, automatic frequency hopping |
| RF power | 23 dBm @ CE/FCC |
| Control range | up to 9 km |
| Battery | 10,000 mAh, 5-6 hours endurance |
| Charging | USB-C |
| Interfaces | PPM, network port, USB-C |
| Operating temperature | -10 °C to 50 °C |
| Dimensions | 225.3 × 66.9 × 120 mm |
| Weight | 480 g |
| Receiver GR01 | 2.4/5.8 GHz, 7.2-80 V (XT30), 1 data port, 1 LAN, 1 SBUS, 3 PWM, 37 g |
Application Scenarios
- UAV flight and payload control
- Line patrol and area survey missions
- Security and perimeter operations
- Emergency response coordination
- Maritime and mountain operations
