CUAV X7+ Pro CORE
CUAV X7+ Pro CORE is a modular flight-controller core for custom carrier-board integration.
- Triple-IMU failover
- Custom carrier-board support
- Dedicated DroneCAN power interface
$869
Product overview
CUAV X7+ Pro CORE is a modular controller core built around the X7+ Pro hardware platform. It combines an STM32H743 processor, triple IMU architecture, RM3100 compass and 14 PWM outputs, and can be paired with a compatible carrier board.
Product features
- STM32H743 Cortex-M7 processor with a double-precision floating-point unit.
- Triple IMUs support intelligent failover switching and temperature compensation.
- A dedicated DroneCAN power interface supports the modular controller design.
- The CORE module can be paired with a compatible CUAV carrier board, including CAN PDB.
Published technical specifications
| Parameter | Published value |
|---|---|
| Processor | STM32H743 Cortex-M7, 480 MHz, 2 MB flash, 1 MB RAM |
| IMUs | ADIS16470, ICM-42688-P and ICM-20689 |
| Compass | RM3100 |
| Barometers | MS5611 × 2 |
| PWM outputs | 14; M1–M12 support DShot |
| UART / I²C | 5 UART / 6 I²C |
| CAN / GPS | 2 CAN buses / 2 GPS ports |
| Operating temperature | −20 to 85 °C |
Product videos
Integration and quotation
Include the carrier-board design, connector plan, firmware target, airframe, quantity and destination in the quote request.
- Aircraft type and available mounting space
- Target firmware and required connectors, buses and outputs
- Power source, peripheral voltage and package options
- Quantity and destination for the quotation
